Manufacturer Price HDPE Waterproof Geomembrane Tank Sheet As Agriculture Pond Dam Liner

1. Corrosion resistance

2. good water resistance

3. Long lasting

4. Specifications can be customized

Color:
Model Number:
Thickness:
Width:
Length:
Package:
Standard:
Availability:
Quantity:
  • geomembrane

  • zhongloo

  • geomembrane

Manufacturer Price HDPE Waterproof Geomembrane Tank Sheet As Agriculture Pond Dam Liner

contact informations


Products Description

Introduction:
High density polyethylene(HDPE) smooth geomembrane, made of virgin resin by special production, has even and smooth surface on both sides. It is especially designed for flexible geomembrane.
Specificatio:
Thickness ranges from 0.2mm to 2.0mm, width from 1m to 8m. The roll length can be made according to design or customer request.
Property:
HDPE smooth geomembrane has excellent chemical and mechanical property, anti-crack property, dimensional stability and anti-aging property, furthermore it can be exposed for anti-UV property.
Application:
Municipal environmental, anti seepage in landscaping and municipal, metallurgy area, anti-corrosion, transportation infrastructure, agriculture reservoir waterproofing project, fisheries aquaculture. Other facilities waterproofing, anti erosion, anti seepage, reinforcement and seepage water collecting, preparation of temporary tank and special structure.
geomembrane detail geomembrane detail

Specification


Manufacturer Price HDPE Waterproof Geomembrane Tank Sheet As Agriculture Pond Dam Liner


Geomembrane Technical Parameter (GB standard)
Spec
Properties
GMS0.5
GMS0.75
GMS1.0
GMS1.25
GMS1.5
GMS2.0
GMS2.5
Thickness
0.5mm
0.75mm
1.0mm
1.25mm
1.5mm
2.0mm
2.5mm
Tensile Properties
(each direction) (≥)
.yield strength
.break strength
.yield elongation
.break elongation


7KN/m
10KN/m
--
600%


10KN/m
15KN/m
--
600%


13KN/m
20KN/m
11%
600%


16KN/m
25KN/m
11%
600%


20KN/m
30KN/m
11%
600%


26KN/m
40KN/m
11%
600%


33KN/m
50KN/m
11%
600%
Density(≥)
0.940g/cc
0.940g/cc
0.940g/cc
0.940g/cc
0.940g/cc
0.940g/cc
0.940g/cc
Puncture Restistance (≥)
120N
180N
240N
300N
360N
480N
600N
Carbon Black Content
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
Carbon black Dispersion
Noted(1)
Noted(1)
Noted(1)
Noted(1)
Noted(1)
Noted(1)
Noted(1)
Tear Resistance (≥)
56N
84N
115N
140N
170N
2255N
280N
Oxidative Induction Time(OIT)
Standare OIT(≥)

60min.

60min.

60min.

60min.

60min.

60min.

60min.



WORKSHOP
geomembrane workshop
