Ted Bakerbule Lagoon Epdm Geomembranes Hdpe Geomembrane 0.5mm Pond Dam Liner Tank

1. Corrosion resistance

2. good water resistance

3. Long lasting

4. Specifications can be customized

Color:
Model Number:
Thickness:
Width:
Length:
Package:
Standard:
Availability:
Quantity:
  • geomembrane

  • zhongloo

  • geomembrane

Ted Bakerbule Lagoon Epdm Geomembranes Hdpe Geomembrane 0.5mm Pond Dam Liner Tank

contact informations


Products Description

high density polyethylene(HDPE) smooth liner ,made of virgin resin by special production ,has even and smooth surface on both sides.It is especially designed for flexible geomembrane liner.


Features

  • Good physical and mechanic performance

  • High tearing resistance, strong deformation adaptability

  • Puncture-resisting, aging resisting, ultra-violet radiation, oil and salt, and corrosion resistance

  • Good adaptability to high and low temperature, non-toxicity, long service life

  • Good waterproof, drainage, anti-seepage and damp proof effects

  • Complete width and thickness specifications, low cost and easy installation.


Applications

1. Environmental protection and sanitation like waste landfill, sewage treatment, industrial waste, etc.

2. Water conservancy such as anti-seepage, leakage blockage and reinforcement of river, etc.

3. Municipal projects such as underground project, subway, planting roof, etc.

4. Landscape garden such as artificial river, bottom lining, damp-proof, etc.

5. Mine industry such as bottom lining and anti-seepage

6. Traffic facilities such as road foundation and anti-seepage of subway and culvert.

7. Agriculture such as anti-seepage of ditch, channel, reservoir, pool and irrigation system.



The Geomembrane is Waterproof and impermeable UV resistance,High tearing resistance ,Puncture-resisting,Non toxic,Long life.Root resistance.
geomembrane detail geomembrane detail

Specification


Ted Bakerbule Lagoon Epdm Geomembranes Hdpe Geomembrane 0.5mm Pond Dam Liner Tank


Product name HDPE /LDPE /lldpe geomembrane/pond liner
Usage Waterproof and seepage control project
Color Black/white/blue/double color
Material HDPE/LDPE/LLDPE/EVA
Type HDPE
Thickness 0.1mm-3.0m 1m-8m in roll width, the length as client's request
Service valid term More than 10 years!
Payment term L/C D/A D/P T/T Western Union Money Gram
Packing detail Packing in woven bags. Keep it away from fire.
Property Good flexible ,UV treated,Excellent environmental stress cracking resistance property,Low temperature resistance, corrosion resistance, aging resistance.
Specific Use Municioal environmental project, water conservancy projects,Landfill cap, mining heap leach pads,Pond liner, canal linings, tank,linings, raw water treatment reservoirs, retention ponds,Waste water treatment lagoon, secondary containment



Geomembrane Technical Parameter (GB standard)
Spec
Properties
GMS0.5
GMS0.75
GMS1.0
GMS1.25
GMS1.5
GMS2.0
GMS2.5
Thickness
0.5mm
0.75mm
1.0mm
1.25mm
1.5mm
2.0mm
2.5mm
Tensile Properties
(each direction) (≥)
.yield strength
.break strength
.yield elongation
.break elongation


7KN/m
10KN/m
--
600%


10KN/m
15KN/m
--
600%


13KN/m
20KN/m
11%
600%


16KN/m
25KN/m
11%
600%


20KN/m
30KN/m
11%
600%


26KN/m
40KN/m
11%
600%


33KN/m
50KN/m
11%
600%
Density(≥)
0.940g/cc
0.940g/cc
0.940g/cc
0.940g/cc
0.940g/cc
0.940g/cc
0.940g/cc
Puncture Restistance (≥)
120N
180N
240N
300N
360N
480N
600N
Carbon Black Content
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
2.0-3.0%
Carbon black Dispersion
Noted(1)
Noted(1)
Noted(1)
Noted(1)
Noted(1)
Noted(1)
Noted(1)
Tear Resistance (≥)
56N
84N
115N
140N
170N
2255N
280N
Oxidative Induction Time(OIT)
Standare OIT(≥)

60min.

60min.

60min.

60min.

60min.

60min.

60min.



WORKSHOP
geomembrane workshop



Our Project Cases


Ted Bakerbule Lagoon Epdm Geomembranes Hdpe Geomembrane 0.5mm Pond Dam Liner Tank


Pond liner geomembrane is a kind of smooth, high quality HDPE geomembrane liner, which is made of specially formulated original polyethylene resin. This raw material is specially designed for flexible geomembrane applications. The pond liner plastic sheeting contains about 97.5% polyethylene, 2.5% carbon black and traces of antioxidants and heat stabilizers. It does not use other additives, fillers or extenders. The HDPE geomembrane pond liner plastic sheeting has excellent chemical resistance, mechanical properties, environmental stress crack resistance, dimensional stability and thermal aging characteristics. In addition, HDPE geomembrane liner has puncture resistance and tear resistance that are unmatched by other geotechnical products on the market.


The HDPE geomembrane pond liner plastic sheeting has the following advantages.


(1)The geomembrane pond liner can improve the efficiency of salvage. By using HDPE liners, the algae and sludge in the fish pond can be isolated to purify the salvage environment and improve the efficiency of salvage.
(2)The HDPE geomembrane pond liner has can reduce the chance of fish getting sick. The anti-seepage function of the commercial pond liners are particularly good which can block the heavy metal in the fish pond, purify the water environment, and reduce the chance of fish sickness from the ring.
(3)The HDPE geomembrane pond liner can reduce the maintenance cost of fish ponds. The HDPE liners can be used in clean water for 20-30 years, thus reducing the maintenance cost of the fish pond.
(4)HDPE geomembrane liner also can increase the income of farmers. The time saved has been saved, and the chances of fish getting sick have decreased, which naturally increases the income of farmers.
geomembrane project
geomembrane project
customers Can left us a message on our company account. Our sales staff will be introduced the product details of  HDPE Geomembrane and sent product production videos and pictures and inspection certificates to let customers fully understand our professional capabilities in the HDPE geomembrane industry. During the negotiation, we can send samples of geomembrane liner to customers testing. We also can introduce the company’s basic situation, the advantages of our products, and the company’s success stories in fish ponds in recent years. Last but not least, we had also given reasonable suggestions and documentation on how to install, construct and weld in the application of HDPE geomembrane liner in fish pond projects.
Packing & Delivery
Packed in woven geotextile and strength belt or PE film Or packed according to customers' requirements such as mark the company Logo (Export standard package)
